9KW 12V/24V Water Diesel Parking Heater Liquid Hydronic Heaters for Truck Caravans Bus

1
MOQ
on quantity
Price
9KW 12V/24V Water Diesel Parking Heater Liquid Hydronic Heaters for Truck Caravans Bus
Features Gallery Product Description Request A Quote
Features
Specifications
Keyword 3: Webasto Diesel Heater
Keyword 2: Diesel Heater 12V 24V
Keyword 1: Webasto Heater
Function: Engine Heater
Fuel: Diesel
Kilowatt: 9KW
Item Weight: 10kg
Material: Plastic And Steel
Color: Black And Gray
Basic Infomation
Place of Origin: China
Brand Name: jp
Certification: CE&E4
Model Number: FJH
Payment & Shipping Terms
Packaging Details: Carton box
Delivery Time: 5-7 days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 1000 sets / month
Product Description

Hot Selling Fast Shipping 9KW Diesel 24V Water Parking Heater Alike Webasto Heater ( not webasto )

2 Years Warranty

Specification



Heating Medium Coolant
Thermal power Max 9.1KW
Regulating range 2.0~7.6kW 1.8~7.6kW
Fuel Gasoline Diesel
Fuel consumption Max 1.1 l/h
Regulating range 0.25~1.0 l/h 0.19~0.9 l/h

Power supply

(Common battery for the engine)

DC12V DC12/24V
Power consumption Max 90W
Regulating range 37~83W
Working pressure 2.0bar
temperature range Control unit Operation -40~75°c
Storage -40~85°c
Fuel pump Operation -40~20°c
Storage -40~85°c
Water pump circulation(0.15bar) 1650 l/h
Net Weight (Only heater) 4.8kg
Mobile phone control(Optional) No limitation
Remote control(Optional) Without obstacles≤800m
The temperature of coolant when the warm blower is started 45°c



Packaging & Shipping

9kw heater

9kw _MG_7231

Product Description

Introduction

  • The main equipment of environmental protective and highly intelligent remote control parking heater is a small fuel furnace controlled by a single chip microprocessor. Its medium circulation system is connected with the cooling system of an automobile engine. In such a way, the cooling liquid for the engine can be heated by the heater while the engine is not working, so as to increase the temperature of the engine and the interior of the automobile. The engine is made easy to start even at very low temperature and both the drivers and passengers can have a warmer environment.

Structure and working principles

  • The heater is installed by series connection with engine coolant circulation system. First remote control unit or timer give electronic control unit a start signal,then the fuel from fuel tank is jetted on the metal felt of combustion chamber by fuel pump, glow plug can gasify and ignite the small fuel drops when its temperature reaches about 1000℃, engine is heated by the coolant which is heated by the flame in combustion chamber. Warm air blower is starting and blowing the warm air into the compartment when the coolant gets the temperature of warm air blower starts. Alike WEBASTO Heater.

Product Characteristics

  • Delivery terms can be customized.
  • Both as original and installation equipment.
  • Work at any time even in the low ambient temperature.
  • Eliminate idling and reduce fuel consumption.
  • Compact structure, easy install and maintain.
  • When buying a new car, the heater can be dismantled and installed in the new car.
Scope of Application

Heater Applications:

1.Truck, engineering truck, electric vehicle.
2.Medium bus, Coach, Commercial vehicle.
3. All sizes Campers, Vans, Caravans, Motor homes, etc.
4.Transport vehicle of fruit and vegetable in winter.
5. All kinds of special vehicle for field working .
6.All kinds of the ship, yacht.

1



9kw

ORDER NOW!

Controller

19

Why We are Different



JP Heaters VS Other China Heaters
Production Years 20 Years; Few Years on heaters
Export Years 8 Years; Less than 3 Years
Brand Belief & TuiTe; No Brand;
Warranty Two Years; One Year OR Less;
Heater Models

Over 20 Models:



Few Model;



Fuel Diesel & Petrol; Diesel;
Voltage 12V / 24V 12V;
Heater & Part

All Produced within our factory;

No parts from the second factory.

No factory;

All parts from different factories,

They do assemble.

Cost

High Cost:

Factory run full time;

200 Workers with full insurance;

6 days of work each week;

Low Cost:

No factory;

No workers: only relatives or family members;

Unstable work time;

Materials

Plastic Cover: No smell; Smooth Cover;

Glow Plug: 10000 times;

Fan Motor;

ECU: Mother Board;

Fuel Pump: Strictly QC & Test;

Exhaust: 300 Degree temperatures;

Cover: Strong smell, ragged cover;

Glow Plug: Unstable;



Heater Failure Rate Low to 3%; (According to Real Data) High, Heater may not work when you first receive it.
Company Information

JP Science and Technology Int'l Co., Ltd. was established in 1998 in Heilongjiang province. We are the first company that introduced advanced production technic of parking heating from Germany. We have more than ten years of experiences in research, design, develop and produced the air/water parking heater and completed the professional and modular production. The company has an independent R&D organization and its main technical management staff has expertise and capability of developing new products and following the world-leading technology. We have successful development air parking heater with 2KW,2.2KW,4KW,5KW and water parking heater with 5KW,9KW,35KW. With its high quality, reasonable price, and perfect service, we have been awarded CE/E-mark certification and sold well in China (30 provinces, cities and autonomous regions),Iran,Russia,Iceland, Norway, Denmark, France, Sweden,Poland,Canada, USA,Australia,New Zealand,Japan,Korea, Chile, Argentina, etc.
